SYDNEY DOUBLE EGG SWING10
NOTE:
Do not completely tighten.
STEP 3
1. Insert the back frame (4) to the seat frame (5). Lining
up the bolt holes on the back frame (4) with the
corresponding bolt holes on the seat frame (5)
2. Using M6x45 combination bolt with washer (D), M6
washer (E) and M6 nut (F), lightly tighten all bolts using
the hex key (N) and the wrench (O).
3. Tighten all bolts, then add M6 screw cover (J) as shown
below.
4. Attach the plastic muffler (L) to the hook of back frame
(4).
5
J
E
X1
X4
X4
4
F
D
L
X1
X4
X4
X2
N
O
X1
X1
F
E
D
J
L
L
5
5
4
4
To Next Page
