SYDNEY DOUBLE EGG SWING6
HARDWARE LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
F M6 Nut 4
J M6 Screw Cover 4
H M8 Spring washer 12
L Plastic Muffler 4
G M8 Washer 16
K M8 Screw Cover 4
I M8 Nut 12
M Post Plastic Part 2
A M8x55 Bolt 4
C M8x15 Bolt 4
E M6 Washer 4
B 8
D 4
M8x30 Combination
Bolt and Washer
M6x45 Combination
Bolt and Washer
