SYDNEY DOUBLE EGG SWING8
STEP-BY-STEP GUIDE
STEP 1
1. Attach the lower hanging bar (2) to the base (1) by
lining up the bolt holes on the lower hanging bar (2) with
the corresponding bolt holes on the base (1).
2. Using M8x30 combination bolt and washer (B), M8
washer (G), M8 spring washer (H) and M8 nut (I), lightly
tighten all bolts using the hex key (N) and wrench (O).
3. Using M8x15 bolt (C), M8 spring washer (H), M8 washer
(G), lightly tighten all bolts using the hex key (N).
4. Tighten all bolts.
2
H
C
X2
X12
X4
1
G
B
I N
O
X1
X12
X8
X8 X1
X1
2
2
G
G
H
I
H
C
B
1
