STEP 2
Fasten the chair arms
2
to the chair frame
1
through
the holes on the side of the seat panel, using screws
B
,
washers
C
and hex key
D
.
When assembled, tighten all screws with hex key
D
.
2
1
2
B
C
C
X4
D
X1
B
X4
NOTE:
Do not fully tighten screws
until you have assembled
the chair. Once assembly is
complete, then fully tighten
each screw.
8
10
BAFFIN SECTIONAL SET
