Canvas BAFFIN 088-2273-0 User Manual

STEP 2
Attach the chair base 1 to the other back panel 2 using
screws
A
, washers
C
and hex key
D
, aligning the holes.
When assembled, tighten all screws with hex key
D
.
1
2
2
X1
C
X3
D
X1
A
X3
NOTE:
Do not fully tighten screws
until you have assembled
the chair. Once assembly is
complete, then fully tighten
each screw.
C
A
16
BAFFIN SECTIONAL SET
