STEP-BY-STEP GUIDE
STEP 16
C
X6
Insert 6 cam locks C along the top of the assembled case. Align the top 10
with the holes on gable left 3 and gable right 7 and insert. Tighten and lock
the 6 cam locks C.
C
C
C
10
3
160°~185°
DUNCAN DESK26
Note: Make sure cams are fully tightened and
unit is stable before step 17.
7
