MERCIER BALCONY DINING TABLE8
STEP 2
Line up the bolt holes on the support tube (3) with the
corresponding bolt holes on the long table leg (1). Insert
M6x20 combination bolt and washer (A) and lightly
tighten the bolts using the hex key (B). Do not completely
tighten until all assembly is completed. Repeat the above
steps for the remaining support tube.
B
X1
A
X8
NOTE:
Do not completely tighten.
A
A
3
1
1
X2
3
X2
