NOMENCLATURE PLAN B
BT10C
N° Désignation Description Ref
1 Couvercle Cover BT10C-B1
2 Joint 25*40*10 Gasket 25*40*10 BT10C-B2
3 Roulement 6204 Bearing 6204 BT10C-B3
4 Pignon 160x110x18 Pinion 160x110x18 BT10C-B4
5 Bague Ring BT10C-B5
6 Arbre Shaft BT10C-B6
7 Entretoise Cross-piece BT10C-B7
8 Bague Ring BT10C-B8
9 pignon pinion BT10C-B9
10 Rondelle Washer BT10C-B10
11 Entretoise Cross-piece BT10C-B11
12 Ressort Spring BT10C-B12
13 Butée Block stop BT10C-B13
14 Pignon Pinion BT10C-B14
15 Couvercle Cover BT10C-B15
16 Roulement 6001 Bearing 6001 BT10C-B16
