NOMENCLATURE PLAN E
BT30C & BT40C
N° Désignation Description Ref
1 Bouchon Tape BT43C-E1
2 Poignée Handle BT30C-E2
3 Vis M6*10 Screw M6*10 BT30C-E3
4 Vis M5*16 Screw M5*16 BT30C-E4
5 Entretoise Cross piece BT30C-E5
6 Joint O 36.5*1.8 O gasket 36.5*1.8 BT30C-E6
7 Ressort Spring BT30C-E7
8 Bille Ball BT30C-E8
9
Circlips Circlips BT30C-E9
10 Joint O 15*2.65 O gasket 15*2.65 BT30C-E10
11 Moyeu Hub BT30C-E11
12 Entretoise Cross-piece BT30C-E12
13 Goupille 3*25 Pin 3*25 BT30C-E13
Ref
BT40C-E1
BT40C-E2
BT40C-E3
BT40C-E4
BT40C-E5
BT40C-E6
BT40C-E7
BT40C-E8
BT40C-E9
BT40C-E10
BT40C-E11
BT40C-E12
BT40C-E13
