CORRECTION - Aout. 2009
58
Tel. +33 1 60 02 19 19 - Fax. +33 160 28 91 42
SAV tel. + 33 1 60 02 20 11 - sav@caplainmachines.com
999 Rue du Tuboeuf - BP.99
77170 Brie Comte Robert
FRANCE
NOMENCLATURE PLAN H
BT30C & BT40C
N° Désignation Description Ref
1 Vis M6*25 Screw M6*25 BT30C-H1
2 Couvercle planétaire Planetary cover BT30C-H2
3 Bague Ring BT30C-H3
4 Ecrou M18 Nut M18 BT30C-H4
5 Grille mobile Protection grid BT30C-H5
6 Protection fixe Protection grid BT30C-H6
7 Roue dentée Gear BT30C-H7
8 Vis M8*15 Screw M8*15 BT30C-H8
9
Pignon planétaire Planetary pinion BT30C-H9
10 Roulement 6203 Bearing 6203 BT30C-H10
11 Roulement 6204 Bearing 6204 BT30C-H11
12 Joint 25*50*10 Gasket 25*50*10 BT30C-H12
13 Clavette 5*18 Key 5*18 BT30C-H13
14 Axe porte outil Tool axle
BT30C-H14
15 Goupille Pin BT30C-H15
Ref
BT40C-H1
BT40C-H2
BT40C-H3
BT40C-H4
BT40C-H5
BT40C-H6
BT40C-H7
BT40C-H8
BT40C-H9
BT40C-H10
BT40C-H11
BT40C-H12
BT40C-H13
BT40C-H14
BT40C-H15
