CORRECTION - Aout. 2009
60
Tel. +33 1 60 02 19 19 - Fax. +33 160 28 91 42
SAV tel. + 33 1 60 02 20 11 - sav@caplainmachines.com
999 Rue du Tuboeuf - BP.99
77170 Brie Comte Robert
FRANCE
NOMENCLATURE PLAN A
BT60C
N° Désignation Description Ref
1 Rondelle Washer BT60C-A1
2 Couvercle Cover BT60C-A2
3 Roue dentée Pinion BT60C-A3
4 Butée Engager BT60C-A4
5 Arbre central Central shaft BT60C-A5
6 Bague Ring BT60C-A6
7 Pignon Pinion BT60C-A7
8 Joint Gasket BT60C-A8
9 Entretoise Cross-piece BT60C-A9
10 Rondelle Washer BT60C-A10
11 Pignon Pinion BT60C-A11
12 Bague Ring BT60C-A12
13 Joint 60*90*10 Gasket 60*90*10 BT60C-A13
14 Roulement 6210 Bearing 6210 BT60C-A14
15 Joint 50*80*10 Gasket BT60C-A15
16 Bague Ring BT60C-A16
17 Clavette 12*8*60 Key 12*8*60 BT60C-A17
18 Bague Ring BT60C-A18
19 Circlips Ø42*1.5 Circlips Ø42*1.5 BT60C-A19
20 Ecrou M4 Nut M4 BT60C-A20
21 BT60C-A21
22 Support Support BT60C-A22
23 Ressort Ø8*1*18 Spring Ø8*1*18 BT60C-A12
24 Vis M4*30 Screw M4*30 BT60C-A23
25 Roulement 6207 Bearing 6207 BT60C-A24
26 Joint Ø24 Gasket Ø24 BT60C-A25
27 Ecrou M24 Nut M24 BT60C-A26
