NOMENCLATURE PLAN B
BT60C
N° Désignation Description Ref
1 Axe transmission Gear axle BT60C-B1
2 Roulement 80207 Bearing 80207 BT60C-B2
3 Bague Ring BT60C-B3
4 Pignon Pinion BT60C-B4
5 Baugue Ring BT60C-B5
6 Pignon Pinion BT60C-B6
7 Bague Ring BT60C-B7
8 Roue dentée Gear BT60C-B8
9 Bague Ring BT60C-B9
10 Roue dentée Gear BT60C-B10
11 Vis M10*20 Screw M10*20 BT60C-B11
12 Joint Gasket BT60C-B12
To Next Page
