NOMENCLATURE PLAN F
BT60C
N° Désignation Description Ref
1 Vis M6*16 Screw M6*16 BT60C-F1
2 Joint Gasket BT60C-F2
3 Rondelle Washer BT60C-F3
4 Poulie Pulley BT60C-F4
5 Vis M6*25 Screw M6*25 BT60C-F5
6 Roulement 6004 Bearing 6004 BT60C-F6
7 Entretoise Cross-piece BT60C-F7
8 Vis M4*14 Screw M4*14 BT60C-F8
9 Cage à roulement Bearing cover BT60C-F9
10 Axe transmission Transmission axle BT60C-F10
11 Clavette 5*12 Key 5*12 BT60C-F11
12 Pignon Pinion BT60C-F12
13 Circlips Circlips BT60C-F13
14 Carter Carter BT60C-F14
15 Bouchon Cover BT60C-F15
16 Ecrou M12 Nut M12 BT60C-F16
17 Joint Gasket BT60C-F17
18 Joint Gasket BT60C-F18
19 Engrenage Gear BT60C-F19
20 Clavette 8*12 Key 8*12 BT60C-F20
21 Pignon Pinion BT60C-F21
22 Joint Gasket BT60C-F22
23 Roulement 6005 Bearing 6005 BT60C-F23
24 Joint 30*45*10 Gasket 30*45*10 BT60C-F24
25 Engrenage Gear BT60C-F25
26 Bague Ring BT60C-F26
27 Clavette 6*25 Key 6*25 BT60C-F27
28 Arbre Shaft BT60C-F28
29 Clavette 6*28 Key 6*28 BT60C-F29
30 Axe Axle BT60C-F30
31 Poulie moteur Motor pulley BT60C-F31
32 Moteur Motor BT60C-F32
33 Bouton Button BT60C-F33
34 Bouton arrêt urgence Emergency stop button BT60C-F34
35 Poignée changement vitesse Speed handle BT60C-F35
