17Instruction manual Extraction MotorsPlease keep this instruction manual for future reference
DDMEXT28
This product has been designed to be installed under a kitchen cabinet, corresponding to the
downdraft lower air outlet. This product can work only if it is used in combination with a Caple
downdraft. This product is designed to efficiently exhaust fumes and odours. We recommend
you use the product in Recirculation Mode only and to use a constant diameter piping of
150mm or similar sections.
We also recommend using ducting without elbows, as they negatively affect the performance of
the appliance.
400mm
400mm
100mm
