Instruction manual DI632 41
Please keep this instruction manual for future reference
The dishwasher must be level for proper dish rack operation and wash performance.
1. Place a spirit level on door and rack track inside the dishwasher as shown to check that the
dishwasher is level.
2. Level the dishwasher by adjusting the three levelling legs individually.
3. When levelling the dishwasher, please pay attention not to let the dishwasher tip over.
FIGURE 8
Illustration of
feet adjustment
UP
DOWN
Check level
front to back
Check level
side to side
NOTE:
The maximum
adjustment height of
the feet is 50 mm
NOTE:
The maximum adjustment height of the feet is 50mm.
FEET EXTENSIONS:
Feet extensions are supplied. These can be fitted by inserting into the base of the existing feet, and
tightening the locking nut at the top of the feet extensions to secure them into position.
