Caple DI652 - Page 24

Instruction manual DI65224
Please keep this instruction manual for future reference
Adjusting the upper basket
The height of the upper basket can be easily adjusted to accommodate taller dishes
in either the upper or lower basket.
To adjust the height of the upper rack, follow these steps:
4
1 2
Remove the upper basket.
3
Re-attach the upper basket to upper or
lower rollers.
Pull out the upper basket.
Push in the upper basket.
Type 1:
1
To raise the upper basket, just lift the
upper basket at the center of each side
until the basket locks into place in the
upper position. It is not necessary to lift
the adjuster handle.
2
adjust handles on each side to release
the basket and lower it to the lower
position.
To lower the upper basket,
lift the
Type 2:
13
Lower
position
Upper
position
ADJUSTING THE UPPER BASKET
TYPE 1:
The height of the upper basket can be easily adjusted to accommodate taller dishes in either the
upper or lower basket.
To adjust the height of the upper rack, follow these steps:
