Modular Standard HP Chiller for Carel driver
Carel code +030221236- Rel. 1.0 dated 7 July 2003
40
17.3 ALARM TABLE
Code Alarm description OFF
Compressors
OFF
Fans
OFF
Pump
OFF
System
Reset
Aut/Man
Delay Enablements
CHILLER
AL01 Serious alarm * * * * man no enablable from both
master and slave
AL02 Antifreeze alarm * * * settable no you can select from
manual and
automatic resetting
AL03 Evaporator Pump thermal cutout * * * * man no
AL04 Condenser Pump thermal cutout * * * * man no
AL05 Evaporator flow-switch * * * man settable enablable from both
master and slave
AL06 Condenser flow-switch * * * man settable
AL10 Low pressure pressure-switch 1 *Circuit 1 man settable
AL11 Low pressure pressure-switch 2 *Circuit 2 man settable
AL12 High pressure pressure-switch 1 *Circuit 1 man no
AL13 High pressure pressure-switch 2 *Circuit 2 man no
AL14 Oil differential pressure switch 1 *Circuit 1 man settable
AL15 Oil differential pressure switch 2 *Circuit 2 man settable
AL16 Comp. 1 thermal cutout *Comp. 1 man no
AL17 Comp. 2 thermal cutout *Comp. 2 man no
AL20 Fan 1 thermal cutout * man no
AL21 Fan 2 thermal cutout * man no
AL22 Fan 3 thermal cutout * man no
AL23 High pressure Transducer 1 *Circuit 1 * man no
AL24 High pressure Transducer 2 *Circuit 2 * man no
AL30 B1 probe failed * * * * auto. 60 sec.
AL31 B2 probe failed * * * * auto. 60 sec.
AL32 B3 probe failed auto. 60 sec.
AL33 B4 probe failed auto. 60 sec.
AL34 B5 probe failed auto. 60 sec.
AL35 B6 probe failed auto. 60 sec.
AL36 B7 probe failed auto. 60 sec.
AL37 B8 probe failed auto. 60 sec.
AL40 Pump Maintenance man
AL41 Comp. 1 maintenance man..
AL42 Comp. 2 maintenance man.
AL50 Unit 1 offline auto. 30 sec.
AL51 Unit 2 offline auto. 30 sec.
AL54 Evaporator thermal cutout man.
AL55 32k clock card failed man.
DRIVER 1
AL56 Driver1 - probe Error *Circuit man.
AL57 Driver1 - EEPROM Error * Circuit man.
AL58 Driver1 - EEV Motor Error *Circuit man.
AL59 Driver1 - Battery Error *Circuit man.
AL60 Driver1 - Evaporation high pressure man Settable
AL61 Driver1 - Evaporation low pressure (LOP) man Settable
AL62 Driver1 - Low Super-Heat *Circuit man Settable
AL63 Driver1 - Valve not shut during power-
down
*Circuit man.
AL64 Driver1 - Intake high temperature man Settable
AL74 Time-out for non-shut valve, EEPROM or
battery not charging driver 1
*Circuit man.
AL76 Driver 1 offline *Circuit man. 30 sec.
DRIVER 2
AL65 Driver2 - Probe Error *Circuit man.
AL66 Driver2 - EEPROM Error *Circuit man.
AL67 Driver2 - EEV Motor Error *Circuit man.
AL68 Driver2 - Battery Error *Circuit man.
AL69 Driver2 - Evaporation high pressure (MOP) man Settable
AL70 Driver2 - Evaporation low pressure (LOP) man Settable
AL71 Driver2 - Low Super-Heat *Circuit man Settable
AL72 Driver2 - Valve not shut at power-down *Circuit man.
AL73 Driver2 - Intake high temperature man Settable
AL75 Time-out for non-shut valve, EEPROM or
battery not charging driver 2
*Circuit man
AL77 Driver 2 offline *Circuit man. 30 sec.
