SPARE PARTS LIST
ITEM NO BARCODE
PRODUCT NAME
PART NO QTYDESCRIPTION
4892793140980 M40S MAIN CHASSIS MAIN CHASSIS 114098 M40P0101-01
4892793140997 M40S SERVO SAVER SET
SERVO SAVER HORN
SERVO SAVER HORN BUSH
SAVER
5mm SERVO SAVER
2.6x10 PWB
1
1
1
1
1
14099
M40P0204
M40P0205
M40P0207
91368P0801
SSW-G00032
4892793141031 M40S STEERING HUB SET14103
4892793141048 M40S REAR UPRIGHT SET14104
LEFT FRONT SPINDLE
RIGHT FRONT SPINDLE
LEFT HUB CARRIER
RIGHT HUB CARRIER
1
1
1
1
M40P0401-01
M40P0402-01
M40P0403-01
M40P0404-01
4892793141147 M40S STEERING POST SET14114
LEFT STEERING ARM
RIGHT STEERING ARM
STEERING LINKAGE
SERVO SCREW ROD 3x10PB
1
1
1
2
M40P0801-01
M40P0802-01
M40P0805
SSW-G00196
4892793149945 M40B HINGE PIN BRACE14994
FF HINGE PIN BRACE
FR HINGE PIN BRACE
RR HINGE PIN BRACE
RF HINGE PIN BRACE
1
1
1
1
M40P0305-02
M40P0306-02
M40P0307-02
M40P0308-02
4892793149983 M40B / M40DT PLASTIC LINKAGE SET14998
FRONT LINKAGE
STEERING LINKAGE
LONG BALL CAP
SCREW ROD 3x36
4
2
2
1
M40BP0201
M40BP0202
M40P1301
MASM061A
4892793149938 M40B SLIPPER PINION SET14993
M4 LOCKNUT
SLIPPING SHAFT
PINION GEAR 20T
RING
WAVE WASHER
RING
M3x3 SCREW
1
1
1
1
2
1
1
MASM1011A
MASM2141A
MASM2146A
MASM2161A
MASM716A
MASM889A
MASM038A
4892793150019 M40B WASHER SET15001
BUSH RING 4.1x5.3x2
RING
SPRING WASHER
RING
RING
WAVE WASHER
RING
BUSH RING 4.1x5.3x5.5
SPACER 1.5
2
1
2
4
1
2
1
4
4
MASM667A
MASM346A
MASM1185A
MASM212A
MASM2161A
MASM716A
MASM889A
MASM668A
R14P1111
LEFT REAR SPINDLE
RIGHT REAR SPINDLE
1
1
M40P0405-01
M40P0406-01
4892793141062 M40S UPPER DECK + CHASSIS BRACE + MOTOR MOUNT14106
UPPER DECK
CHASSIS BRACE
MOTOR MOUNT
1
1
1
M40P0203-02
M40P0806
M40P0701
4892793150002 M40B / M40DT BEARING SET15000
BEARING 8x12x3.5mm
BEARING 4x10x3mm
BEARING 5x11x4mm
4
5
8
MASM033A
MASM035A
MASM034A
4892793150033 M40B BALL STUD SET15003
4.8 BALL STUD
BALL STUD
5.8 BALL STUD
6
8
4
MASM013A
M40BP0204
MASM204A
4892793141116 M40S BATTERY BRACE SET14111
BATTERY BRACE
BATTERY POST
1
2
M40P0503
M40P1003
4892793141123 M40S SUSPENSION PIN SET14112 PIN D3.175 X 48.3mm 2MASM1724A
4892793141390 M40S SPUR GEAR 72T14139 SPUR GEAR 72T 1M40P0905-01
4892793141321 M40S OUTDRIVE14132 OUTDRIVE 4MASM004A
4892793141369 M40S PINION GEAR 20T + M3 SCREW SET14136
PINION GEAR 20T
M3x3 SCREW
1
1
MASM059A
MASM038A
4892793149860 M40B WHEEL HEX14986
WHEEL HEX
PIN D2x10
4
4
M40P0209
MASM017A
4892793149877 M40B PLASTIC OIL SHOCK SET 14987
FRONT OIL SHOCK
REAR OIL SHOCK
2
2
MAT-010-SA-00004
MAT-010-SA-00005
4892793148344 BODY POST SET14834 BODY POST 4M40P1004
4892793149853 M40B WHEELS AND TYRE SET (PAIR)14985 M40B WHEELS AND TYRE SET 2MAT-010-TA-00002
4892793149891 M40B / M40DT GEAR BOX DUST COVER14989 GEAR BOX DUST COVER 1M40P0208
4892793149921 M40B DOG BONE(PAIR)14992 DOG BONE 2MASM2145A
4892793149907 M40B SHOCK TOWER SET14990
SHOCK TOWER
SHOCK TOWER MOUNT
2
4
M40BP0101
M40BP0102
4892793149914 M40B / M40DT SUSPENSION ARMS (FRONT & REAR) SET14991
FRONT SUSPENSION ARMS
REAR SUSPENSION ARMS
2
2
M40BP0103
M40BP0104
4892793150026 M40B LOCKNUT SET15002
M3 SCREW NUT
M4 SCREW NUT
6
4
MASM1168A
MASM1011A
