4.8.4 Pull the headrest handle, the shoulder straps will be moved together,
select correct height and x them in the correct position for the child
by releasing the headrest handle.
Pull the headrest handle
4.9 Adjusting the headrest in an installation that uses the vehicle safety belt – groups
II and III.
4.9.1 A correctly adjusted headrest ensures that the diagonal seat belt section
is optimally positioned, and gives your child the optimal protection.
4.9.2 The headrest must be adjusted so that a space equivalent to two ngers
remains between the headrest and the child’s shoulders.
4.9.3 Pull the headrest handle to adjust headrest to the correct height,
then release the headrest handle. Place the safety seat on the car seat,
put the child in the seat and check the height.
4.9.4 Repeat the process until the correct height is achieved.
