Option A: Installing Your Gate Between Two Walls
STEP 1
Unfold the gate frame at each
pivoting joint by loosening each
cap.
STEP 2
Determine the size of your opening. If you need to remove panels from your gate simply
unhook the upper and lower knobs between the panels. If you are adding panels, hook together
opposite panel ends; one panel with the male side and one panel with the female side. Check to
make sure all the panels are securely locked.
