1.1 - R-410A - General info
• This air conditioner adopts the new HFC refrigerant
(R410A) which does not destroy ozone layer.
• R-410A refrigerant operates at 50%-70% higher
pressures than R-22. Be sure that servicing equipment
and replacement components are designed to operate
with R-410A.
• R-410A refrigerant cylinders have a dip tube which
allows liquid to ow out with the cylinder in a vertical
position with the valve at the top.
• R-410A systems should be charged with liquid
refrigerant. Use a commercial type metering device in
the manifold hose in order to vaporize the liquid
refrigerant before it enters in the unit.
• As for other HFC, R-410A refrigerant is only
compatible with oils recommended by the compressor
manufacturer.
• A vacuum pump is not enough to remove moisture
from oil.
• Oils absorb moisture rapidly. Do not expose oil to
atmosphere.
• Never open system to atmosphere while it is under
vacuum.
• When the system must be opened for service, break
vacuum with dry nitrogen.
• Do not vent R-410A into the atmosphere.
Use this unit only for factory approved applications.
The capacity and unit code are stated on the nameplate
data.
CAUTION:
• Do not leave system open to atmosphere any longer
than minimum required for installation.
• Oil in the compressor is extremely susceptible to
moisture absorption.
 
30AWH004H- 30AWH004X-
30AWH006H- 30AWH006X-
30AWH008H- 30AWH008X-
30AWH012H- 30AWH012X-
30AWH015H- 30AWH015X-
1
30AWH
Air / Water Cycle Heat Pump
t This air conditioner adopts the new HFC refrigerant
(R410A) which does not destroy ozone layer.
t R-410A refrigerant operates at 50%-70% higher pressures
than R-22. Be sure that servicing equipment and
replacement components are designed to operate with
R-410A.
t R-410A refrigerant cylinders have a dip tube which allows
liquid to ow out with the cylinder in a vertical position
with the valve at the top.
t R-410A systems should be charged with liquid
refrigerant. Use a commercial type metering device in the
manifold hose in order to vaporize the liquid refrigerant
before it enters in the unit.
t As for other HFC, R-410A refrigerant is only compatible
with oils recommended by the compressor manufacturer.
t A vacuum pump is not enough to remove moisture from
oil.
t Oils absorb moisture rapidly. Do not expose oil to
atmosphere.
t Never open system to atmosphere while it is under
vacuum.
t When the system must be opened for service, break
vacuum with dry nitrogen.
t Do not vent R-410A into the atmosphere.
Use this unit only for factory approved applications.
The capacity and unit code are stated on the nameplate
data.
R-410A - General info
SITING THE UNIT
INSTALLATION
R-410A - General info .......................................................... 1
Safety procedures ................................................................ 2
Dimensions and clearances............................................... 4
Technical data ....................................................................... 4
Installation ............................................................................. 5
Water connections ............................................................... 6
Electrical connections ......................................................... 8
Connection of Auxiliary Accessories .............................. 9
System test ............................................................................. 12
Unit protection devices ...................................................... 15
Maintenace ............................................................................ 15
Contents Page
WATER CONNECTIONS
ELECTRICAL CONNECTIONS
CONTROL WIRING (Optional)
POWER WIRING
FILLING THE SYSTEM
FLUSHING WATER AND AIR
CHECKING FOR WATER LEAKS
CONFIGURING AND CHECKING THE SYSTEM
CAUTION:
t Do not leave system open to atmosphere any longer
than minimum required for installation.
t 0JMJOUIFDPNQSFTTPSJTFYUSFNFMZTVTDFQUJCMFUP
moisture absorption.
MODELS WITH HYDRONIC
MODULE
MODELS WITHOUT
HYDRONIC MODULE
30AWH004H- 30AWH004X-
30AWH006H- 30AWH006X-
30AWH008H- 30AWH008X-
30AWH012H- 30AWH012X-
30AWH015H- 30AWH015X-
English
