Carrier 38AYC - Page 20

20
Detailed cooling capacities*
See notes on pg. 21.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38AYC048-33, 34 Outdoor Section With F(A,B)4BN(F,B,C)048 Indoor Section
1400
72 51.0 25.3 3.97 49.1 24.7 4.43 47.0 24.0 4.94 44.7 23.2 5.49 42.3 22.4 6.08
67 47.4 32.8 3.95 45.3 32.0 4.40 43.1 31.1 4.90 40.6 30.1 5.44 38.2 29.2 6.02
63†† 43.8 31.8 3.92 41.8 30.9 4.37 39.7 30.0 4.86 37.6 29.1 5.39 35.2 28.1 5.95
62 43.1 39.5 3.91 41.1 38.5 4.36 39.2 37.5 4.85 37.1 36.5 5.38 34.9 34.9 5.94
57 41.8 41.8 3.90 40.2 40.2 4.35 38.6 38.6 4.84 36.9 36.9 5.38 35.0 35.0 5.94
1600
72 51.6 26.3 4.05 49.7 25.7 4.51 47.6 25.1 5.02 45.3 24.3 5.58 42.8 23.5 6.17
67 48.2 34.8 4.03 46.0 34.0 4.49 43.7 33.1 4.99 41.2 32.2 5.53 38.7 31.2 6.11
63†† 44.6 33.7 4.01 42.5 32.8 4.46 40.3 31.9 4.95 38.1 31.0 5.48 35.7 30.0 6.04
62 44.0 42.2 4.00 42.0 41.1 4.45 40.1 39.9 4.94 38.2 38.2 5.48 36.3 36.3 6.05
57 43.4 43.4 3.99 41.7 41.7 4.45 40.0 40.0 4.94 38.2 38.2 5.48 36.2 36.2 6.05
1800
72 52.1 27.3 4.13 50.2 26.7 4.60 48.1 26.1 5.11 45.7 25.4 5.66 43.2 24.7 6.25
67 48.8 36.8 4.11 46.6 36.0 4.57 44.2 35.2 5.07 41.7 34.2 5.61 39.1 33.1 6.20
63†† 45.2 35.6 4.09 43.0 34.7 4.54 40.8 33.8 5.03 38.5 32.8 5.56 36.1 31.7 6.13
62 44.9 44.5 4.08 43.0 43.0 4.54 41.2 41.2 5.04 39.3 39.3 5.58 37.2 37.2 6.16
57 44.7 44.7 4.08 43.0 43.0 4.54 41.2 41.2 5.04 39.3 39.3 5.58 37.3 37.3 6.15
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section
Unit
Size
Cooling
Indoor
Section
Unit
Size
Cooling
Capacity Power Capacity Power
CC5A/CD5AA 060 1.00 1.00 FK4DNF 005 1.04 0.95
CC5A/CD5AC 048 0.97 0.98
COILS + 58CV(A,X)090-16 FURNACE
CC5A/CD5AW 048 0.99 0.99 CE3AA 060 1.00 0.93
060 1.02 0.99
COILS + 58CV(A,X)110-22 FURNACE
CD5AA 048 0.98 0.98 CC5A/CD5AA 060 1.00 0.94
CE3AA 048 1.00 0.99 CE3AA 060 1.00 0.91
060 1.03 0.99 CK3BA 060 1.00 0.92
CF5AA 048 0.98 0.97 CK5A/CK5BA 060 1.00 0.92
CK3BA 048 0.99 0.99 CK5A/CK5BT 060 1.00 0.92
060 1.00 0.97 CK5A/CK5BX 060 1.00 0.90
CK5A/CK5BA 048 0.99 0.99
COILS + 58CV(A,X)135-22 FURNACE
060 1.00 0.97 CC5A/CD5AA 060 1.00 0.94
CK5A/CK5BT 048 0.99 0.99 CC5A/CD5AW 060 1.00 0.92
060 1.00 0.97 CE3AA 060 1.00 0.92
CK5A/CK5BW 048 0.99 0.99 CK3BA 060 1.00 0.92
CK5A/CK5BX 060 1.02 0.97 CK5A/CK5BA 060 1.00 0.92
F(A,B)4BN(F,B,C) 048 1.00 1.00 CK5A/CK5BT 060 1.00 0.92
060 1.03 1.02 CK5A/CK5BX 060 1.00 0.90
FB4BNB 070 1.04 1.00
COILS + 58CV(A,X)155-22 FURNACE
FC4CN(F,B) 048 1.00 1.00 CC5A/CD5AA 060 1.00 0.93
060 1.04 1.03 CC5A/CD5AW 060 1.00 0.91
FC4CNB 054 1.04 0.99 CE3AA 060 1.00 0.91
070 1.03 0.98 CK3BA 060 1.00 0.92
FG3AAA 048 0.98 0.98 CK5A/CK5BA 060 1.00 0.92
060 1.00 0.98 CK5A/CK5BT 060 1.00 0.92
FK4DNB 006 1.03 0.90 CK5A/CK5BX 060 1.00 0.90
