Carrier 38CJR018-723 - Outdoor Unit Construction View

– 11 –
FILE NO. SVM-05010
2-5. Outdoor Unit (38HNR018-713)
A
A Detail Drawing

∅
6 hole
R10

∅
11x14 hole

∅
25 Drain outlet
Fan guard

Electric Parts cover
Liquid side (Flare
∅
6.35)
Gas side (Flare
∅
12.7)
Installation dimension
100 or more
Air inlet
600 or more
100 or more
Air inlet
Air
outlet
600 or more
600
50 35
600
344
325
91 54
60
50
90
600
830
90
120
52
23
325
Handle
538
300
Service Port
4x∅11x14
for ∅8 − ∅10
anchor bolt
8-∅6 holes
(for fixing outdoor unit)
6-∅11x14 holes (for ∅8 − ∅10 anchor bolt)
