56 Specifications subject to change without notice. SG-38MARB-01
Check Procedures
Temperature Sensor Check
1. Disconnect the temperature sensor from PCB.
2. Measure the sensor’s resistance value using a multi-meter.
3. Check the corresponding temperature sensor’s resistance value table.
Fig. 43 — Test
Be sure to turn off all power supplies or disconnect all wires
to avoid shock.
Operate after the compressor and coil have returned to a
normal temperature in case of injury.
WAR N I N G
To Next Page
