Electrical connections
Heat pump - 40KQV 050, 080, 110, 130
1 2 3
1 2 3
1
10
80
Notes:
• See outdoor unit installation manual.
Terminal box legend, all models
Earth
1 Live connection indoor/outdoor unit
2 Neutral connection indoor/outdoor unit
3 Communication (high voltage)
Cable passage
Interconnection cable (4x1 mm
2
/ H07 RN-F)
Room Controller/CZM connecting cable
(optional – see installation manual CRC/CZM)
Minimum section of connecting cable conductors
for inside and outside units (mm
2
)
Models 123
40KQV 050, 080, 110, 130 1,0 1,0 1,0 1,0
