6
DIMENSIONS, WEIGHTS AND MINIMUM CLEARANCES (Cont.)
4-2 INDOOR UNITS
42QG SERIES
DIMENSIONS (mm)
Weight
Model Kg
42QG18 14
42QG24 14
MINIMUM CLEARANCES FOR FREE AIR CIRCULATION, SERVICE AND MAINTENANCE
Kg
1080 185
Mounting Plate
Main Body
Connection Tube
Drain Hose
295
