APPENDIX D: SystemVut Controller CCN Tables
Service Config Tables (cont)
TABLE DISPLAY NAME VALUES UNITS POINT NAME WRITE STA TUS
IDF_CFG (cont)
IDF Min Start RPM xxxx RPM IDFSTSPD 300
IDF Start Speed Time xxx sec IDFSSTIM 30
IDF Curve High End PWM 0 to 100 % IFMHIPWM 97
IDF Curve Low End PWM 0 to 100 % IFMLOPWM 10
COOL_CFG
Compressor Min On Time 180 t o 600 sec C_MINON 300
Compressor Min Off Time 120 to 600 sec C_MINOFF 180
Runtime to Reset Strikes 120 to 999 sec MIN_ON_S 300
Cool Stage Increase Time 120 to 999 sec CSTAGINC 450
Cooling SAT Trend Level --- 1 t o 1 SAT_TLC --- 0 . 2
Cool Min SAT Upper Level 35.0 to 65.0 °F SATMIN_H 56
Cool Min SAT Lower Level 35.0 to 65.0 °F SATMIN_L 46
Cooling Fan ---Off Delay 0 to 600 sec COOL_FOD 75: All except below
30: Size 07
90: 48/50GC 06
ODF High Speed Time 0 to 300 sec MINODFTM 120
ODF Relay Enabled Yes/No OFR_EN No: 48/50FC
Yes: 48/50GC
CircuitALockoutTemp --- 20 to 75 °F OATLCMPA 40: no FIOP
0: Humidi---MiZerFIOPorLowAmbient
FIOP
Low Cool lockout Temp --- 20 to 60 °F LCL OCKSP 10
Humidimizer Equipped Ye s/No HUMZ_EN N o : N o H u m i d i --- M i Z e r F I O P
Ye s : H u m i d i --- M i Z e r F I O P
Humidimizer Lockout Temp --- 20 t o 75 °F OATLHUMZ 40
Low Refrig Charge Level 0 to 150 PSI LOCHARGE 50
Low Charge Disable Temp --- 40 t o 50 °F LOCH_LOT 10
CirA High Pressure Limit 400 to 700 PSI HIPLIM_A 670
Low Discharge Level 0to20 °F SDTLEV 0
Minimum Pressure Ratio 0to5 MINPSI_R 1.35
Suction OK Temperature 10 to 50 °F SSTOK 18
Low Suction Level 1 Temp 10 to 50 °F SSTLEV1 20
Low Suction Level 2 Temp 5to50 °F SSTLEV2 15
Low Suction Level 3 Temp 0to50 °F SSTLEV3 10
Delay On Low SST Check 0 to 300 sec SSTCKDLY 0: no FIOP
40: Humidi --- MiZer FIOP
Comp Level 2 Diag Delay 1to99 sec CDDTLEV2 15
Diag Comp Unexpected Off Enable/Disable CD_UEOFF Enable
Circuit Stuck On Diag. Enable/Disable DCKTOFF Enable
Min discharge change 0to99 PSI MDP_DISA 8
Min Suction change 0to99 PSI MDP_SUCA 10
CirA P.Ratio off change --- 1 t o 1 OFFPR_A --- 0 . 3
Compressor Framework 0to2 0to2 SYSVTYPE 1: All except below
2: 48/50FC 04--- 06
0=2Compressors
1 = Compressor + Loader
2 = Compressor Only
Comp A1 Shutdown First Yes/No SDWN_A1 No
Comp Loader Shutdown 1st Ye s/No SDWN_ALD Yes: All except below
No: 48/50FC 04--- 06
Fan Based Dehum Type 0=NONE,
1=Comfort,
2=Max
FBD_TYPE 0 = NONE
FBDH Low Set Point --- 2 0 t o 0 ΔF FBDLO_SP --- 2 . 5
FBDH Max Mode SST SP 20 to 60 °F FBDSSTSP 38
FBDH Min SST Threshold 10 to 60 °F FBDH_SST 32
FBDH Comfort SAT SP 35 to 80 °F FBDH_ SAT 46
FBD Comfort SAT Delta 0to30 °F FBDSATDT 11
