Carrier AquaForce 30XB series - Electrical Data

29
4.5 - Electrical data
30XB & 30XBP from 250 to 1000
30XB 30XBP 250 300 350 400 450 500 600 700 750 800 850 900 1000
Power circuit supply
Nominal voltage V-ph-Hz 400-3-50
Voltage range V 360-440
Control circuit supply 24 V via internal transformer
Maximum operating input power
(1)
- 30XB
Standard unit kW 119 133 147 168 195 214 264 285 319 338 367 392 454
Unit + option 15LS kW 112 126 140 159 185 204 251 271 305 324 353 378 437
Maximum operating input power
(1)
- 30XBP
Standard unit kW 117 131 145 165 192 211 259 279 314 333 362 386 447
Unit + option 15LS kW 114 127 141 160 187 206 252 272 306 325 354 379 438
Power factor at maximum power
(1)
- 30XB
Standard unit
Displacement Power Factor (Cos Phi) 0,88 0,88 0,88 0,88 0,89 0,89 0,89 0,89 0,89 0,89 0,89 0,90 0,90
Unit + option 15LS
Displacement Power Factor (Cos Phi) 0,88 0,88 0,88 0,88 0,89 0,89 0,89 0,89 0,89 0,89 0,89 0,90 0,90
Power factor at maximum power
(1)
- 30XBP
Standard unit
Displacement Power Factor (Cos Phi) 0,88 0,88 0,88 0,88 0,89 0,89 0,89 0,89 0,89 0,89 0,89 0,90 0,90
Unit + option 15LS
Displacement Power Factor (Cos Phi) 0,88 0,88 0,88 0,88 0,89 0,89 0,89 0,89 0,89 0,89 0,89 0,90 0,90
Nominal operating current draw
(2)
- 30XB
Standard unit A 151 167 182 210 239 267 324 349 402 430 446 511 541
Unit + option 15LS A 141 157 172 197 226 254 306 330 383 411 427 492 519
Nominal operating current draw
(2)
- 30XBP
Standard unit A 145 161 176 202 231 259 313 337 390 418 434 499 527
Unit + option 15LS A 139 155 170 194 223 251 302 325 378 406 422 487 513
Maximum operating current draw (Un)
(1)
- 30XB
Standard unit A 198 220 242 278 319 349 430 464 519 549 595 634 734
Unit + option 15LS A 188 210 232 265 306 336 412 445 500 530 576 615 711
Maximum operating current draw (Un)
(1)
- 30XBP
Standard unit A 192 214 236 270 311 341 419 452 507 537 583 622 720
Unit + option 15LS A 186 208 230 262 303 333 408 440 495 525 571 610 706
Maximum current (Un-10%)
(1)
- 30XB
Standard unit A 198 220 242 278 319 349 430 464 519 549 595 634 734
Unit + option 15LS A 188 210 232 265 306 336 412 445 500 530 576 615 711
Maximum current (Un-10%)
(1)
- 30XBP
Standard unit A 192 214 236 270 311 341 419 452 507 537 583 622 720
Unit + option 15LS A 186 208 230 262 303 333 408 440 495 525 571 610 706
Nominal start-up current
(3)
- 30XB
Standard unit A 246 246 261 379 479 479 535 561 734 757 760 843 857
Unit + option 15LS A 245 245 262 378 480 480 536 562 735 759 761 845 865
Unit + option 25C A 213 224 224 346 442 442 492 492 676 691 691 733
756
Nominal start-up current
(3)
- 30XBP
Standard unit A 240 240 255 371 471 471 524 549 722 745 748 831 843
Unit + option 15LS A 234 234 249 363 463 463 513 537 710 733 736 819 829
Unit + option 25C A 207 218 218 338 434 434 481 480 664 679 679 721 742
Maximum start-up current(Un)
(2)
- 30XB
Standard unit A 274 274 292 407 510 510 583 616 782 812 812 902 951
Unit + option 15LS A 264 264 282 394 497 497 565 597 763 793 793 883 929
Unit + option 25C A 213 224 224 346 442 442 492 492 676 691 691 733 756
Maximum start-up current(Un)
(2)
- 30XBP
Standard unit A 268 268 286 399 502 502 572 604 770 800 800 890 937
Unit + option 15LS A 262 262 280 391 494 494 561 592 758 788 788 878 923
Unit + option 25C A 207 218 218 338 434 434 481 480 664 679 679 721 742
(1) Values obtained at unit continuous maximum operating conditions (data given on the unit nameplate)
(2) Operating current of the smallest compressor(s) + fan current + locked rotor current or reduced start-up current of the largest compressor.
(3) Standardised EUROVENT conditions, water-cooled exchanger water inlet/outlet = 12°C/7°C, outdoor air temperature = 35°C.
4 - PHYSICAL AND ELECTRICAL DATA FOR 30XB UNITS
