Carrier AquaForce 30XV400 - Displayed Text; Capacity Control

270
APPENDIX A — CARRIER CONTROLLER DISPLAY TABLES (cont)
*Depends on the selected language (English by default).
CAPACTRL — Capacity Control
Carrier Controller PATH:
Main Menu  Maintenance Menu
 Capacity Control
LINE DISPLAYED TEXT* CCN NAME RANGE
DEFAULT
VALUE
UNIT
READ/
WRITE
1 Controlled Water Temp
ctrl_wt —
— °F (°C) RO
2 Ctrl Water Temp, Deg/Min
cwt_rate —
— °F (°C) RO
3 Current Capacity Limit
cap_lim 0 to 100
100 % RO
4 Wished Comp. Frequency A
drvcmda —
—HzRO
5 Capa Ctrl State A
capstata —
——RO
6 Capa Ctrl State Text A
captxta —
——RO
7 Override State A
ovrstata —
——RO
8 Override State Text A
ovrtxta —
——RO
9 Capa Ctrl Stat Nb A
capmoda —
——RO
10 Last Capa Ctrl Stat Nb A
lcapmoda —
——RO
11 Override Capacity Nb A
overrida —
——RO
12 Estimated Capacity A
cap_pc_a 0 to 100
—%RO
13 Wished Comp. Frequency B
drvcmdb —
—HzRO
14 Capa Ctrl State B
capstatb —
——RO
15 Capa Ctrl State Text B
captxtb —
——RO
16 Override State B
ovrstatb —
——RO
17 Override State Text B
ovrtxtb —
——RO
18 Capacity Ctrl Stat Nb B
capmodb —
——RO
19 Last Capa Ctrl Stat Nb B
lcapmodb —
——RO
20 Override Capacity Nb B
overridb —
——RO
21 Estimated Capacity B
cap_pc_b 0 to 100
—%RO
22 Max Comp. Frequency A
cMaxFrqA —
95 Hz RO
23 Max Comp. Frequency B
cMaxFrqB —
95 Hz RO
24 Comp. VI Cmd A
viCmdA —
——RO
25 Comp. VI Cmd B
viCmdB —
——RO
26 Reset Amount
reset —
— °F (°C) RO
27 Circuit Running Number
CirRunNb —
——RO
28 State of Circuit A
StatCirA —
——RO
29 State of Circuit B
StatCirB —
——RO
30 Dual Circuit Master
DualMast —
——RO
31 Transfer Spd, add cir
xSpdHigh 0 to 0
60 Hz RO
32 Transfer Spd, remove cir
xSpdLow 0 to 0
30 Hz RW
33 Compressor Start Freq
cStrtFrq 0 to 0
26 Hz RO
34 Compressor Min Frequency
cMinFrq 0 to 0
26 Hz RO
35 DGT A, Deg/min
dgt_dt_a —
— °F (°C) RO
36 SST A, Deg/min
sst_dt_a —
— °F (°C) RO
37 DGT B, Deg/min
dgt_dt_b —
— °F (°C) RO
38 SST B, Deg/min
sst_dt_b —
— °F (°C) RO
LEGEND
RO — Read Only
RW — Read/Write
Spt — Set Point
