9 - NOMINAL SYSTEM WATER FLOW RATE CONTROL
9.1 - Available static pressure for the installation
Units with hydraulic module (xed-speed pump or variable-speed pump at 50 Hz)
Data applicable for:
- Pure water at 20°C.
- Refer to the "Water exchanger water ow" section for the maximum water ow values.
- If ethylene glycol is used, the maximum ow rate is reduced.
9.1.1 - Units 040R-160R
High pressure pumps
Single pumps
Sizes 040R - 080R
Available static pressure, kPa
Water ow rate, l/s
50
60
70
80
90
100
110
120
130
140
150
160
170
180
190
200
210
220
0,01,0 2,03,0 4,05,0 6,0
1
B
C
D
E
F
G
1 30RB - 040R
2 30RB - 045R
3 30RB - 050R - 55R
4 30RB - 060R
5 30RB - 070R
6 30RB - 080R
Sizes 090R-160R
Available static pressure, kPa
Water ow rate, l/s
50
60
70
80
90
100
110
120
130
140
150
160
170
180
190
200
210
220
230
0,01,0 2,03,0 4,05,0 6,07,0 8,09,0 10,0
H
I
J K l
7 30RB - 090R
8 30RB - 100R
9 30RB - 120R
10 30RB - 140R
11 30RB - 160R
