FED “B” Series: Installation Instructions & Homeowner’s Information
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
6
Notes:
1.Airflow based upon dry coil at 230V with factory-approved filter and electric heater; airflow at 208V is approximately the same as 230V because the ECM motor is a constant torque
motor. The torque doesn’t drop off at the speeds the motor operates.
2.To avoid potential for condensate blowing out of drain pan prior to making drain trap, Return static pressure must be less than 0.40 in. wc.
3.Airflow above 400 cfm/ton on 4800 - 6000 size could result in condensate blowing off coil or splashing out of drain pan.
Table 3 – Airflow Performance - without Cooling Coil (CFM)
Size Blower Speed
Total Static (inches water column)
0.10 0.20 0.30 0.40 0.50 0.60
FED002410*
Tap 5 1123 1081 1032 993 967 914
Tap 4 1015 934 892 857 800 737
Tap 3 1015 942 892 856 804 738
Tap 2 1012 833 761 705 643 585
Tap 1 1014 829 627 560 496 441
FED003610*
FED003612*
FED003615*
Tap 5 1492 1453 1425 1398 1364 1335
Tap 4 1382 1348 1314 1286 1255 1219
Tap 3 1383 1347 1313 1285 1254 1218
Tap 2 1223 1182 1151 1122 1079 1039
Tap 1 1165 1123 1092 1060 1012 973
FED004815*
Tap 5 1991 1954 1919 1888 1850 1811
Tap 4 1885 1849 1811 1776 1737 1692
Tap 3 1889 1846 1812 1778 1739 1690
Tap 2 1630 1584 1547 1499 1449 1403
Tap 1 1480 1431 1385 1332 1280 1237
FED006020*
Tap 5 2069 2031 2005 1977 1945 1912
Tap 4 1857 1824 1795 1760 1727 1689
Tap 3 1859 1822 1794 1760 1725 1688
Tap 2 1699 1664 1635 1595 1553 1509
Tap 1 1569 1482 1403 1355 1308 1263
Table 4 – Airflow Performance - with Accessory Cooling Coil (CFM)
Size Blower Speed
Total Static (inches water column)
0.10 0.20 0.30 0.40 0.50 0.60
FED002410*
TAP 5 976 924 859 790 736 690
TAP 4 810 774 710 661 605 568
TAP 3 850 786 721 672 625 585
TAP 2 735 661 601 549 504 449
TAP 1 590 541 489 440 383 333
FED003610*
FED003612*
FED003615*
TAP 5 1266 1234 1208 1174 1138 1106
TAP 4 1239 1210 1177 1145 1107 1072
TAP 3 1229 1201 1170 1141 1110 1076
TAP 2 1107 1074 1039 1007 973 937
TAP 1 1048 1016 979 941 906 867
FED004815*
TAP 5 1615 1598 1566 1534 1504 1464
TAP 4 1533 1504 1471 1439 1399 1359
TAP 3 1549 1517 1474 1438 1404 1360
TAP 2 1330 1299 1258 1218 1181 1140
TAP 1 1218 1185 1148 1102 1056 978
FED006020*
TAP 5 1879 1849 1820 1789 1758 1724
TAP 4 1686 1656 1622 1588 1557 1522
TAP 3 1696 1662 1631 1599 1567 1532
TAP 2 1559 1520 1486 1451 1414 1376
TAP 1 1356 1323 1290 1247 1198 1156
