FED “B” Series: Installation Instructions & Homeowner’s Information
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
7
1. All values are calculated at 230 volts.
2. Wire size must be in accordance with the applicable revision of the NEC and all other applicable codes.
3. Amperage ratings may vary. Verify correct Amperage listing to ensure adequate breaker size for over-current protection.
4. Use copper wire only.
Table 5 – Electrical Data, Fan Coil Only, with Electric Heat
Model Heater kW Circuit Motor Amps Heater Amps Min Circuit Amps Breaker Size
FED002410* 10 KW SINGLE 2.8 40 53.6 60
FED003610* 10 KW SINGLE 4.1 40 55.1 60
FED003612* 12 KW
A (L1,L2)
4.1
31.7 44.8 50
B (L3,L4) 15.8 19.8 20
FED003615* 15 KW
A (L1,L2)
4.1
40 55.1 60
B (L3,L4) 20 25 25
FED004815* 15 KW
A (L1,L2)
6
40 57.5 60
B (L3,L4) 20 25 25
FED006020* 20 KW
A (L1,L2)
6
40 57.5 60
B (L3,L4) 40 50 50
