Detailed cooling capacities* continued
See notes on pg. 38.
EVAP
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38TSA024-34 Outdoor Section With CK5PA036 Indoor Section continued
700
57 23.23 23.23 1.50 22.33 22.33 1.71 21.33 21.33 1.94 20.26 20.26 2.18 19.12 19.12 2.46 17.80 17.80 2.74
62 23.96 21.89 1.50 22.79 21.34 1.71 21.57 20.75 1.94 20.30 20.13 2.18 19.12 19.12 2.46 17.80 17.80 2.74
67 26.27 18.51 1.50 24.97 17.96 1.72 23.60 17.40 1.95 22.15 16.80 2.20 20.59 16.17 2.47 18.88 15.49 2.76
72 28.86 15.13 1.51 27.44 14.59 1.73 25.95 14.02 1.96 24.35 13.43 2.21 22.62 12.80 2.48 20.73 12.11 2.77
800
57 24.25 24.25 1.53 23.25 23.25 1.75 22.19 22.19 1.98 21.06 21.06 2.23 19.80 19.80 2.50 18.40 18.40 2.79
62 24.51 23.56 1.54 23.33 22.95 1.75 22.19 22.19 1.98 21.06 21.06 2.23 19.80 19.80 2.50 18.40 18.40 2.79
67 26.76 19.73 1.54 25.41 19.18 1.76 23.99 18.60 1.99 22.48 18.00 2.24 20.88 17.36 2.51 19.09 16.65 2.79
72
29.38 15.89 1.55 27.91 15.34 1.76 26.35 14.77 2.00 24.69 14.17 2.25 22.92 13.53 2.52 20.93 12.82 2.81
900
57 25.08 25.08 1.57 24.04 24.04 1.79 22.91 22.91 2.02 21.69 21.69 2.27 20.36 20.36 2.54 18.88 18.88 2.83
62 25.06 25.06 1.57 24.04 24.04 1.79 22.91 22.91 2.02 21.69 21.69 2.27 20.36 20.36 2.54 18.88 18.88 2.83
67 27.13 20.90 1.58 25.74 20.34 1.79 24.29 19.74 2.03 22.76 19.13 2.27 21.08 18.46 2.54 19.25 17.72 2.83
72
29.77 16.61 1.59 28.25 16.06 1.80 26.65 15.48 2.04 24.95 14.87 2.29 23.10 14.22 2.56 21.05 13.51 2.84
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
CK3BA 024 0.97 0.89 CE3AA 024 0.97 0.92
030 0.97 0.89 030 0.97 0.90
036 1.00 0.91 036 1.00 0.92
CK5A/CK5BA 024 0.97 0.90 CK5A/CK5BW 036 1.00 0.91
030 0.97 0.90 CK5PW 036 1.00 0.91
036 1.00 0.91
COILS + 58CV(A,X)155-22 VARIABLE SPEED FURNACE
CK5A/CK5BT 036 1.00 0.91 CC5A/CD5AW 036 1.00 0.91
CK5A/CK5BW 024 0.97 0.90 CE3AA 024 0.97 0.91
030 0.97 0.90 030 0.97 0.90
036 1.00 0.91 036 1.00 0.92
CK5PA 024 0.97 0.90 CK5A/CK5BW 036 1.00 0.91
030 0.97 0.90 CK5PW 036 1.00 0.91
036 1.00 0.91
COILS + 58MVP040-14 VARIABLE SPEED FURNACE
CK5PT 036 1.00 0.91 CC5A/CD5AW 036 1.00 0.92
CK5PW 024 0.97 0.90 CE3AA 024 0.97 0.92
030 0.97 0.90 030 0.97 0.91
036 1.00 0.91 036 1.00 0.93
COILS + 58CV(A,X)110-20 VARIABLE SPEED FURNACE CK5A/CK5BW 036 1.00 0.91
CC5A/CD5AA 036 1.00 0.92 CK5PW 036 1.00 0.91
CC5A/CD5AW 024 0.97 0.92
COILS + 58MVP060-14 VARIABLE SPEED FURNACE
030 0.97 0.91 CC5A/CD5AA 024 0.97 0.92
036 1.00 0.91 030 0.97 0.91
CE3AA 024 0.97 0.92 036 1.00 0.92
030 0.97 0.91 CC5A/CD5AW 024 0.97 0.92
036 1.00 0.93 030 0.97 0.91
CK3BA 024 0.97 0.89 036 1.00 0.92
030 0.97 0.90 CE3AA 024 0.97 0.92
036 1.00 0.91 030 0.97 0.91
CK5A/CK5BA 036 1.00 0.91 036 1.00 0.93
CK5A/CK5BT 036 1.00 0.91 CK3BA 024 0.97 0.90
CK5A/CK5BW 024 0.97 0.91 030 0.97 0.90
030 0.97 0.90 036 1.00 0.91
036 1.00 0.91 CK5A/CK5BA 024 0.97 0.91
CK5PA 036 1.00 0.91 030 0.97 0.91
CK5PT 036 1.00 0.91 036 1.00 0.91
CK5PW 024 0.97 0.91 CK5A/CK5BT 036 1.00 0.91
030 0.97 0.90 CK5A/CK5BW 024 0.97 0.91
036 1.00 0.91 030 0.97 0.90
COILS + 58CV(A,X)135-22 VARIABLE SPEED FURNACE 036 1.00 0.91
CC5A/CD5AW 036 1.00 0.91 — — —
