3
Model number nomenclature
Physical data
NOTE:
See unit Installation Instructions for proper installation.
* For tubing sets greater than 50 ft horizontal and/or 20 ft vertical differential, consult Residential Split System Long-Line Application Guideline and
Service Manual.
†TXV not factory supplied.
CHARGING SUBCOOLING (TXV-TYPE EXPANSION DEVICE
*
)
* Must be a Puron® approved hard shutoff TXV.
Accessories
38TSA 024 3 3 1
14 SEER Split-System
Air Conditioner Packaging
Series
Nominal Capacity
024 — 24,000 Btuh 042 — 42,000 Btuh
030 — 30,000 Btuh 048 — 48,000 Btuh
036 — 36,000 Btuh 060 — 60,000 Btuh
Electrical
3 — 208/230-1
Unit Size-Series 024-34 030-33 036-33 042-33 048-31 060-30
Operating Weight (Lb)
290 290 293 294
312 362
COMPRESSOR
Type
Scroll
REFRIGERANT
Puron® (R-410A)
Control
TXV (Hard Shutoff)†
Charge (Lb)
9.35 9.11 9.83 9.66
12.00 15.00
COND FAN
Propeller Type, Direct Drive
Air Discharge
Vertical
Air Qty (CFM)
2400 2400 2800 2800 2800 3800
Motor HP
1/8 1/8 1/5 1/5
1/15 1/5
Motor RPM
825 825 825 825
825
825
COND COIL
Copper Tube, Aluminum Plate Fin
Face Area (Sq ft)
15.2 18.25 18.25 18.25
18.3 24.5
Fins per In.
20 20 20 20
20
20
Rows
2222
2
2
Circuits
4444
4
6
VALVE CONNECT. (In. ID)
Sweat
Vapor
5/8 3/4
7/8
Liquid
3/8
REFRIGERANT TUBES* (In. OD)
Vapor (0–50 Ft Tube Length)
5/8 3/4 7/8
1-1/8
Vapor (Max Diameter for Long-
Line Applications)
3/4
7/8
1-1/8
Liquid (0–50 Ft Tube Length)
3/8
Liquid (For Long-Line
Applications)
3/8
UNIT SIZE-SERIES REQUIRED SUBCOOLING (°F)
024-34
10
030-33
8
036-33
9
042-33
7
048-31
10
060-30
10
ORDERING NO. DESCRIPTION
KAATD0101TDR
Time-Delay Relay — All Sizes
KSALA0301410
Low-Ambient Pressure Switch — All Sizes
KSALA0401AAA*
MotorMaster® Low-Ambient Controller — All Sizes
KAAFT0101AAA†
Evaporator Freeze Thermostat — All Sizes
KAAWS0101AAA†
Winter Start Control — All Sizes
KSACY0101AAA
Cycle Protector — All Sizes
