Carrier RBM-Y0383FUL - 2-2. FS unit (Flow Selector unit)

– 29 –
2-2. FS unit (Flow Selector unit)
Specifications
Model Name RBM-Y0383FUL RBM-Y0613FUL RBM-Y0963FUL
Power supply 230 V (208/230 V) 1phase 60 Hz
Connectable indoor unit capacity (kBtu/h) Below 38 38 to below 61 61 to 96 or less
Connectable indoor units 588
Height (in) 7.49 7.49 7.88
Width (in)Dimension 9.77 9.77 15.8
Depth (in) 6.3 6.3 7.88
Total Weight (lbs) 11 13 20
Liquid side (in)Connecting port dia.
(Indoor unit side)
3/8" 3/8" 1/2"
Gas side (in) 5/8" 5/8" 7/8"
Liquid side (in)
Connecting port dia.
(Outdoor unit side)
3/8" 3/8" 1/2"
Discharge gas side (in) 1/2" 1/2" 1/4"
Gas side (in) 5/8" 5/8" 7/8"
Connection Blaze connection
External view
(Unit: in (mm))
