Carrier VECTOR 1550 Series - Page 106

62-61753-21
5-12
CONFIGURATION
SELECTIONS
DESCRIPTION
RANGE 1 (or 2) MAXIMUM
TEMPERATURE
-30°C to 32°C
(-22°F TO 89.6°F)
in 0.1°F or °C in-
crements
Select the highest temperature desired for this range.
MINIMUM SETPOINT
-30°C to 30°C
(-22°C TO 89.6°F)
in 0.1°C or C in-
crements
Indicates to the controller the desired minimum allow-
able set point.
MAXIMUM SETPOINT
-30°C to 32°C
(-22°F TO 89.6°F)
in 0.1°F or °C in-
crements
Indicates to the controller the desired maximum al-
lowable set point.
NO AC POWER
ALARM &
SHUTDOWN
SWITCH TO EN-
GINE
ALARM & SHUTDOWN = If standby power is lost unit
is to shut down
SWITCH TO ENGINE = If standby power is lost die-
sel engine will be started.
S/S PARAMETERS
SEPARATE
TOGETHER
TOGETHER = When the Minimum Run Time, Mini-
mum Off Time, Maximum Off Time, and Override
Temperatures are set in the Functional Parameter
List, the same values will be used for both Frozen
and Perishable setpoints.
SEPARATE = When the Minimum Run Time, Mini-
mum Off Time, Maximum Off Time, and Override
Temperatures are set in the Functional Parameter
List, different values may be entered for Perishable
and Frozen setpoints.
REMOTE TEMP SENSOR 1
(or 2 or 3)
ON / OFF
ON = A remote sensor has been added to the unit,
and connected into the wire harness at Remote Temp
Sensor (1 or 2) plug.
OFF = There is no Remote Sensor (1or 2) in this unit.
DOOR SWITCH
SWITCH NOT
INSTALLED
DOOR OPEN
SWITCH OPEN
DOOR OPEN
SWITCH CLOSED
SWITCH NOT INSTALLED = There is no door switch.
DOOR OPEN SWITCH OPEN = A Door Switch has
been installed. The switch contacts will be OPEN
whenever the door is OPEN.
DOOR OPEN SWITCH CLOSED = A Door Switch
has been installed. The switch contacts will be
CLOSED whenever the door is OPEN.
 DOOR SWITCH UNIT
SHUTDOWN
ALARM ONLY
UNIT SHUTDOWN
LOW ENGINE
SPEED
DATA RECORDER
ONLY
ALARM ONLY = When Door Switch indicates that the
door is open, a warning alarm will be displayed in the
MessageCenter.
UNIT SHUTDOWN = When Door Switch indicates
that the door is open, a warning alarm will be dis-
played in the MessageCenter, and the unit will shut-
down.
LOW ENGINE SPEED = When Door Switch indicates
that the door is open, the engine will be forced to low
speed.
DATA RECORDER ONLY = The Data Recorder will
record every time the door is opened or closed. There
will be no alarms or messages displayed in the Mes-
sageCenter.
