Casablanca Fan Co. - Factory Service Department - Technical Library
VII - 7.34
How do you change the PULL CHAIN
SWITCH ONLY? - This is a question that we
are asked over and over again, the informa-
tion in this section of the service manual will
help you. Once you have the right pull chain
switch, changing it only takes a few minutes.
First remove or open up the switch housing
on the fan shown in Figure #1. Now you will
need to look at the pull chain switch you are
replacing. Match it up with one you are going
to replace it with.
Step #1
Remove the knurl nut from the pull chain switch
shown in Figure #2. Pull the switch out of the switch
housing cup with wire attached, as shown in Figure
#2A and remove it from the switch housing cup.
(Figure #1)
(Figure #2)
(Figure #2A)
Pull Chain Switch Replacement - CONTINUED
