Install wiring –
Solenoid equipped units
A Install hoses
B Operate auxiliary valves
(both directions)
C Remove hoses
8
9
Flush hydraulic supply hoses
GA0034.eps
Install hoses
10
SSR
SSL
Forks
Out
Forks
In
FP0026.eps
Fork Positioner with
Standard Valve
Double Internal
Reeving Hydraulic Supply
Sideshifting
Installation Kit 224042
(4 Hoses)
Single Internal
Reeving Hydraulic Supply
Non-Sideshifting
Installation Kit 224041
(2 Hoses)
FP0021.eps
FP0022.eps
7.5 Amp
Fuse
Knob
Button
Solenoid
Coils
Diode
18 gauge wire
1/4 in. Terminals
White
Black
7.5 Amp
Fuse
White
Black
User
Supplied
Wire
Solenoid
Coils
Diode
