Case HI JX95 - Page 27

SECTION 10 -- ENGINE -- CHAPTER 1
11
6-62720 -- 09 -- 2006
(continued)
11. DELIVERY PROGRESSION
Rev/min Delivery per 1000 shots: cm
3
1400 0to3
1250 60.0 to 66.0
1000 65.2 to 70.3
450 63.5 to 70.3
12. ZERO DELIVERY (STOP)
Rev/min Voltage (volts) Delivery per 1000 shots: cm
3
325 0 0to3
13. DELIVERY CHECK AT IDLE SPEED
Rev/min 325 380 --
Delivery per 1000 shots: cm
3
4.0 to 18.0 0to3.0 --
14. AUTOMATIC START SUPPLEMENT
Rev/min Delivery per 1000 shots: cm
3
100 75 to 115
250 60.5 to 74.5
Note: The values shown above in brackets must be used for checking purposes only.
BENCH TEST PERFORMANCE DATA
Test Conditions
TDC fixed advance with cylinder No. 1 in compression stroke:
(see previous page)
Relative humidity 70% ± 5.
Engine without fan, air filter and exhaust silencer. Ambient temperature 25 °C.
Atmospheric pressure: 990 mbar Specific gravity of diesel fuel
830 ± 10 g/litre.
Throttle
l
e
v
e
r
B
r
a
k
i
n
g
l
o
a
d
a
p
p
l
i
e
d
E
n
g
i
n
e
r
p
m
Power output with engine run--in for a to-
tal of:
Fuel
consumption
lever
position
Braking load applied Engine rpm
2 hours
kW (HP)
50 hours
kW (HP)
kg/h
Maximum
For maximum
torque
2500 -- 54.0 -- 57.5 12.3 -- 13.1
Maximum For maximum torque 1500 -- 39.5 -- 42 8.5 -- 9.0
Maximum None (no--load) 2725 ± 25 -- -- --
Minimum None (no--load) 650 ± 25 -- -- --
