Case 721E - Page 38

Engine-Enginecoolingsystem
8.Supportthefuelcooler(5).Removethetwobolts(6)
andthewashers.Removethefuelcooler.
LAIL11CW1069A0A7
9.Iftheloaderisequippedwithairconditioning,unlock
thelatchthatsecurestheairconditioningcondenser,
locatedonthetopoftheframeofthecoolingsystem.
Tilttheairconditioningcondensertoitsverticalposi-
tion.Loosenthetwohoseclamps(7).Removehose
(8).
BRCE12WLCCM067B8
10.Loosenthetwoclampsthatsecurethelowerradiator
hose.Removethelowerhose.
BRCE12WLCCM092A9
11.Removetheradiatorcap(9).Disconnecttheoverll-
ing(overow)hose(10).Installtheradiatorcap.Dis-
connecttheconnectorofthecoolantlevelsender(11).
Removethebolt(12).Installaliftingeye.
LAIL11CW1070A0A10
