Case CRAWLER DOZER 650L TIER3 - Torque Specifications

INTRODUCTION
Torque
Ripper
Component
Torque
Rippermountingbolts
700-1260Nm(515-925lbft)
Ripperpinretainingandtubecoverbolts
145-260Nm(110-190lbft)
HydraulicPump
Component
Torque
NonPTOpump
Coverbolts66-80Nm(50-60lbft)
PTOtypepump
Airvent
9Nm(80lbin)
Pumphousingbolts
271Nm(200lbft)
PTOshaftretainer68Nm(50lbft)
SetscrewPTOshaftretainer9Nm(80lbin)
Shaftcoverscrews8-9Nm(65-75lbin)
EquipmentValve
Component
Torque
Boltsandnutsthatfastenthesectionstogether39-47Nm(29-35lbft)
Reliefvalvesandloadcheckvalves24-30Nm(18-22lbft)
Allenheadscrews
12-15Nm(106-133lbin)
Centeringspringscrew13-16Nm(115-142lbin)
FuseandRelayBlocks
Component
Torque
Fuseblockmounting
2.7Nm(24lbin)
Bussedstuds
8.5Nm(75lbin)
PowerRelays
Component
Torque
Outputstuds5.4Nm(48lbin)
Inputstuds
16.3Nm(144lbin)
EngineMounts
Component
Torque
Enginemountboltstochassis
205-230Nm(151-170lbft)
Rearenginemountbracketstobellhousing
118-133Nm(87-98lbft)
Frontenginemountbrackettoengineblock
125-156Nm(92-115lbft)
Startermountingbolts68-77Nm(50-57lbft)
Component
Torque
Hoseclamps
11-12Nm(97-106lbin)
Lowermountingbolts
68-82Nm(50-60lbft)
EnginetoPumpsDriveShaft
Component
Torque
Flywheelmountbolts
285-305Nm(210-225lbft)
PumpsandMotors
Component
Torque
Pumpmountboltstoframe68-81Nm(50-60lbft).
8426083121/08/2009
7
