INTRODUCTION
AirConditioningCompressor
Component
Torque
Compressorrotorshaftnut15-20Nm(11-15lbft)
Oilllerplug15-24Nm(11-18lbft)
Dustcoverscrews
7-11Nm(5-8lbft)
LiftCylinder
Component
Torque
Pistonbolt
810-925Nm(597-682lbft)
Gland135-542Nm(100-400lbft)
TiltCylinder
Component
Torque
Pistonbolt
810-925Nm(597-682lbft)
Gland135-542Nm(100-400lbft)
AngleCylinder
Component
Torque
Pistonbolt
810-925Nm(597-682lbft)
Gland135-542Nm(100-400lbft)
RipperCylinder
Component
Torque
Pistonbolt
810-925Nm(597-682lbft)
Gland135-542Nm(100-400lbft)
Starter
Component
Torque
Mountingbolts
68-77Nm(50-57lbft)
Batteryterminalnut
17.7-24.5Nm(13-18lbft)
Solenoid+screw2.6-4.5Nm(23-40lbin)
