DISTRIBUTIONSYSTEMS-PRIMARYHYDRAULICPOWERSYSTEM
Reliefvalve-Sectionalview
BS00A0571
(1)Inletportpassage(4)Pilotpassagepoppet
(2)Returnportpassage(5)Jamnut
(3)Mainreliefpoppet(6)Pressureadjustingscrew
8426083121/08/2009
A.10.A/
9
