DISTRIBUTIONSYSTEMS-PRIMARYHYDRAULICPOWERSYSTEM
Reliefvalve-Disassemble
Prioroperation:
StackvalveInletsection-Disassemble(A.10.A)
1.Fastenthemainreliefvalveinavisewithsoftjaws.
Removethecap.
RCPH09CWL193AAD1
2.Holdtheadjustingscrewinpositionwhileyouloosen
thelocknut.
RCPH09CWL192AAD2
3.Removetheadjustingscrew.Makesurethatyou
countthenumberofturnsrequiredtoremovethe
adjustingscrewsothatyoucaninstalltheadjusting
screwcorrectlyduringAssembly.
RCPH09CWL191AAD3
4.Removethespring.
RCPH09CWL444AAD4
