1002 - 5
SPX 4260 Troubleshooting Manual
Issued 2-03 Printed in U.S.A. General Information And Specifications
SPECIFICATIONS
Item Specification
Engine CDC 6TA-830, 260 hp turbo charged and after cooled diesel
Drive Hydrostatic with full-time, 4-wheel drive. Infinitely variable shifting returns the wheel
motor to maximum torque each time the hydrostatic control lever is returned to neu-
tral. Allows maximum torque for each start.
Wheel Adjustment 120 in. - 152 in.
Suspension 4 wheel independent trailing arm with spring and shock standard. Active suspension
optional. 11 in. of travel.
Steering Hydraulic power steering. Orbital with master/slave rephasing cylinders.
Cab Air conditioner and heater with activated charcoal air filter
6 way adjustable suspension seat
2 speed windshield wiper
AM/FM stereo cassette system
Adjustable automotive type steering wheel
Full instrumentation
Tinted glass
Cab lighting
Hydraulic all wheel parking brakes with dynamic disc brakes on front wheels with
brake pedal in cab.
Travel Speed 30 mph / 48 kph
Fuel Tank 140 gallons (399 liters) diesel only
Dimensions Dry weight 24,000 lbs (10,896 kg)
(380/85 R46 tires, 90’ boom)
Tank size 1200 gal (4560 liters) SS
Nozzle spacing 20 in. preset others available
Overall length 336 in. (28 ft. / 8.6 m)
Overall width 138 in. (11 ft. 6 in. / 3.5 m) (retracted)
170 in. (14 ft. 2 in. / 4.4 m) (extended)
Overall height 144 in. (12 ft. / 3.65 m)
Wheel base 150 in. (12 ft. 6 in. / 3.8 m)
Ground clearance 54 in. / 137 cm (tank empty)
52 in. / 132 cm (tank full)
Tire Sizes 380/85 R46
650/65 R38
320/90 R46 (optional)
Turning Radius Axles in - 20 ft. 6 in. / 6.25 m
Axles out - 21 ft. 4 in. / 6.5 m
Boom Boom length 60’-90’
60’-80’ (optional)
Boom tip breakaway 5.5 ft. / 1.68 m
