Case SV340 - Page 38

Engine-Engineandcrankcase
4.Threadthequick-disconnecthoseassembly(1)
(48109944)ontothequick-disconnectdraintting(2)
(48103849).
5.Allowtheoiltodraincompletelyfromthecrankcase.
6.Removethereceptacle,withtheusedoil,fromunder
themachine.
RAPH17SSL0170QA3
7.Removethequick-disconnecthoseassembly(1)
(48109944)fromthequick-disconnectdraintting(2)
(48103849).
RAPH17SSL0170QA4
8.Installthecap(1)(47786509)ontothequick-discon-
nectdraintting(2)(48103849).
NOTE:Makesuretheo-ringisinstalledonthedraintting
(2),ifitisdamaged,thenreplacewithnew.
NOTE:Thecap(1)isonlyhandtightonthedraintting(2).
RAPH17SSL0169QA5
4806031928/08/2017
10.1[10.001]/5
