Engine-Engineandcrankcase
24.DisconnecttheNOxmodule(4),NH3module(3),and
thetemperaturesensor(2).
25.Removeanywireties,P-clamps,andretainersthat
aresecuringthesewires.
26.DetachtheNOxmodule(1)fromthebracketforthe
controlmodules.
RAIL14SSL0792BA16
27.Removetheexhaustclamp(1).
RAIL14SSL0791BA17
28.DetachtheSelectiveCatalyticReduction(SCR)muf-
er(1)fromthemufermountingbracket.Savethe
hardwareforreuse.
29.RemovetheSCRmufer(1).
RAIL14SSL0853BA18
4806031928/08/2017
10.1[10.001]/13
