— 2 —
ELECTRICAL
Current drain with 9 V DC: Nominal Limit
No sound output 330 mA 330 mA ± 20%
Maximum volume 990 mA 990 mA ± 20%
with 16 keys C1 to D3 pressed in Synth-Lead 1
Volume: Maximum, Touch response: ON(Velocity MAX)
Phone output level (Vrms with 8 Ω load each channel): L 240mV 240 mV ± 20%
with key C3 pressed in Synth-Lead 1 R 250mV 250 mV ± 20%
Speaker output level (Vrms with 4 Ω load each channel):
with key G1 pressed in Synth-Lead 1 L/R 2500mV 2500 mV ± 20%
Output level (Vrms with 47 KΩ load each channel): L 2300mV 2300 mV ± 20%
with key C2 pressed in Synth-Lead 1 R 2400mV 2400 mV ± 20%
Minimum operating voltage: 6.3V 7.0V
