Casio CTK-573 Service Manual

PARTS PRICE LIST
CTK-573
N ITEM CODE NO. PART NAME SPECIFICATION Q PRICE CODE R
MAIN PCB
1 1005 3885 PCB ASSY(MA1M) TK-M241539*1(M702) 1
DQ A
LSI1 2012 5572 LSI TC55257DFL-70L(EL) 1
AS A
LSI2 1004 5604 LSI MSM538002E1FGSKDR1 1
AZ A
LSI3 1004 5603 LSI MSM531602F35GSKDR1 1
BH A
LSI4 2012 4998 LSI GT913F 1
BP A
IC1 2105 4746 LSI UPD6379GR-E1 1
AO A
IC2 1002 9549 IC/C-MOS S-816A50AMC-BAZ-T2 1
AD A
IC3 2101 0294 IC/C-MOS TC74HC74AF-TP1 1
AD A
IC4 1004 6049 IC/C-MOS TC74VHC00FT(EL) 1
AC A
IC5 2105 6631 IC/C-MOS TC74VHC08FT(EL) 1
AC A
IC6 1004 7049 IC/C-MOS S-80940ANMP-DD4-T2 1
AC A
Q1 1001 5566 TRANSISTOR 2SB1181TLR 1
AC B
X1 2590 2742 OSCILLATOR/CRYSTAL AT-49-30M 1
AG B
SUB PCB ASSY
2 1005 3886 PCB ASSY(MA2M) TK-M241540*1(M702) 1
CO B
IC101 1004 3474 IC/MONOLITHIC LA4635A 1
AN A
IC102 2114 1421 IC/PHOTO COUPLER PC900V 1
AK B
Q102,Q104-Q108 2250 1627 TRANSISTOR 2SC1740STPS 6
AA A
Q101,Q103 2250 1591 TRANSISTOR 2SB1237TV2R 2
AB A
D101 2390 3021 DIODE SRT14 1
AF B
D105 2390 3018 DIODE 1T2 1
AA B
D103,D106-D108 2315 3132 DIODE 1SS133T-77 4
AA B
D104 2360 1939 DIODE/ZENER MTZJ5.1C-T77-T 1
AA B
J101 3501 7049 JACK/DC HEC2305-01-330 1
AC A
J102 3612 0665 JACK/PHONE YKB21-5006 1
AG B
J103 3612 0789 JACK YKB21-5010 1
AC B
J104 3501 4816 JACK/DIN YKF51-5051 1
AH B
DISPLAY PCB
3 1005 6773 PCB ASSY(LCD1M) TK-M241539*2(M702) 1
CC B
LSI401 1000 6502 LSI ML9040-B02GA 1
AU A
TH401 2590 2177 THERMISTOR TBPS1R103J440H5Q 1
AD B
VR401 2775 3286 POTENTIOMETER/TRIMER EVM3SSX50B53 1
AC B
CONSOLE PCB
4 1005 3887 PCB ASSY(CN1) TK-M241541*1(M702) 1
BL B
5 1005 3888 PCB ASSY(CN2) TK-M341421*1(M702) 1
AP B
D301-D344 2315 3132 DIODE 1SS133T-77 44
AA A
LED301 1004 6705 LED EL-204HD-TR4-7(A) 1
AA B
VR301 2765 2213 VOLUME RS20H121-2KB 1
AD A
KEYBOARD PCB
6 1005 3891 PCB ASSY(KY1M) TK-M140687*9(M702) 1
BK B
7 1005 3893 PCB/ASSY(KY2M) TK-M140688*9(M702) 1
BJ B
D501~D564 2301 0101 DIODE 1S2473-T-77-T 64
AA B
D565~D622 2301 0101 DIODE 1S2473-T-77-T 58
AA B
KEYBOARD UNIT
8 6922 2721 WHITE KEY SET/LT M312118A*1 4
AP A
9 6922 2731 WHITE KEY SET/LT M312118A*2 1
AP A
10 6906 8482 BLACK KEY SET 10P M140369B-3 2
AM A
11 6906 8592 BLACK KEY SET 5P M140369B-4 1
AI A
12 6927 4260 RUBBER/KEY LT SET M340985*1 1
BJ B
Notes:N- New parts
Q- Quantity used per unit
R- Rank
