7. PARTS LIST
FOB Japan
N Item Code No. Parts Name Specification Q M N.R.Yen R
Unit Price
L375-1 ASS'Y
LSI1 2011 0105 LSI HD62076A02 1 1 C
LSI2 2011 1239 LSI HD66108T02 1 1 C
N LSI3 2010 7259 LSI MN4464S-08LL 1 1 C
N LSI4 2011 7280 LSI HN27C301AFP20-61201 1 1 C
IC1 2189 2009 Linear IC LA5311M-TP-T1 1 1 C
N IC2 2105 3213 C-MOS IC BU4066BCF-T1 1 10 C
N IC6 2105 2982 MOS IC S-80250AG-GB-T1 1 5 C
X1 2590 0777 Ceramic oscillator CSAC2.01MGCM001-TC 1 1 C
C1/C2 2845 2499 Chip capacitor MCH215A300JK 2 20 C
C3/C4/C5/C6 2845 1540 Chip capacitor MCH212F104ZK 7 20 C
C7/C8/C20
C9 2845 1925 Chip capacitor MCH312F105ZP 1 10 C
R1 2795 1309 Chip resistor MCR10EZHJ684 1 10 C
R2 2795 3262 Chip resistor MCR10EZHG563 1 20 C
R3 2795 0532 Chip resistor MCR10EZHJ105 1 20 C
R4 2792 0977 Chip resistor MCR10EZHJ154 1 10 C
R5 2792 0209 Chip resistor MCR10EZHJ104 1 20 C
R6 2795 2450 Chip resistor MCR10EZHG182 1 20 C
N R7 2795 0504 Chip resistor MCR10EZHG392 1 20 C
N R8 2730 0622 Chip resistor MCR10EZHG822 1 20 C
N R9 2795 4956 Chip resistor MCR10EZHG163 1 20 C
R21 2795 2184 Chip resistor MCR10EZHG823 1 20 C
N R22 2795 3836 Chip resistor MCR10EZHG203 1 20 C
Q1 2252 0112 Chip transistor 2SC1623-T1B(L6,L7) 1 1 C
N Q2 2250 0413 Chip transistor 2SA1411-T1B(M16) 1 20 C
N VR1 3122 1862 Chip volume MVR32HXBRN203 1 20 C
N 1 5610 7660 Heat seal A-L375 A313350-1 1 1 B
N 2 5610 7670 Heat seal B-L375 A313351-1 1 1 B
N 3 6408 0490 Tape A-L375 A414163-1 1 20 X
4 6405 9090 Tape D-L373 A413732-1 3 20 X
N 5 6408 0450 LCD holder L375 A211376-1 1 20 C
N 6 6407 9930 Flat screw A-L370 A310044-41 1 20 C
N 7 6409 2950 Adhesive tape B-L375 A414588-1 2 20 C
8 6405 9110 Adhesive tape C-L373 A412118-2 2 20 C
N 9 3335 4711 LCD CD777-TS 1 1 C
N 10 6409 2960 PC joiner B-L375 A413642-4 1 5 C
N 13 6408 0410 L375-2 ass'y A211385*1 1 1 C
(This unit contains the above parts as it's element)
N 11 6408 0380 L375-1 ass'y A110928A*1 H 1 1 A
(This unit contains the above parts as it's element)
L375-2 ASS'Y
IC3 2101 0952 MOS IC TC4049BF-TP1 1 1 C
N IC4 2105 3220 CMOS IC RH5VL36CA-T1 1 10 C
N IC5 2105 2982 MOS IC S-80250AG-GB-T1 1 5 C
N C10/C11 2803 6687 Electrolytic capasitor 10RE2-22-T58-T 2 20 C
C12/C17 2845 1540 Chip capacitor MCH212F104ZK 2 20 C
N C13/C16 2803 6701 Electrolytic capacitor 25RC2-4R7-T58-T 2 20 C
C14 2845 1925 Chip capacitor MCH312F105ZP 1 10 C
N C15 2845 4711 Chip capacitor MCH215C152KK 1 20 C
N TR1 3841 1183 Chip coil CM5-01 1 5 C
D1 2390 1407 Chip diode MA998-(TX) 1 10 C
Notes: N – New parts R – A : Essential
M – Minimum order/supply quantity B : Stock recommended
R – Rank C : Others
Q – Quantity used per unit X : No stock recommended
